Poster large format plain screen printing machine

Share to:
    Payment Type: L/C,T/T
    Incoterm: FOB,CIF
    Min. Order: 1 Bag/Bags
    Delivery Time: 15 Days

Basic Info

Model No.: PS-120240PVH

Type: Vertical Screen Printing Machine

Style: Screen-process Printing Press

Color & Page: Single-Colour Printing Press

Working Table: Vacuum Working Table, Size: 1000*1500mm

Actions: Up-down Of Screen Plate

To Be Printed: Plain Objects

Squeegee Stroke: Adjust The Limited Switch

Squeegee And Screen Plate Control: High Precision Linear Guideway

H.s.code: 8443192190

Additional Info

Packaging: Wooden case

Productivity: 50 sets/month

Brand: KC

Transportation: Ocean

Place of Origin: Dongguan

Supply Ability: 20 sets/month

Certificate: CE Certificate

Product Description

Poster large format screen printer with vacuum table

screen-44

Screen Printing Machine could print on all kinds of products, like paper, glass, metals, plastic, and so on. High-precision linear guide control scraper and screen frame to move, ensure the printing precision.This series plain screen printer uses motor-driven system. Vacuum worktable could fix some thin plain products.

Usage


  • It is a flat screen printer with a suction function and is suitable for printing in thin products such as paper, PVC film, plastic film, textile, etc., which are easy to walk in the printing process. Printing the largest area: 600 * 800 mm;
  • Structural design using screen up and down sports, more conducive to product removal and placement;
  • Stable horizontal cylinder design, blowing ink pressure uniform, back to the ink formation, printing quality is good;
  • Can be semi-automatic operation, the user interface is good;
  • Machine debugging process set up a single function operation, set up to complete the full operation;
  • Widely used in paper packaging, mirror printing, glass printing, machine panels, stickers printing, combined with a variety of processes, can achieve UV scrub, UV onions, UV local varnish and coating process. Also widely used in water mark transfer paper, thermal transfer paper printing.
  • Screen printing machine and the Screen Plate are used up and down the use of high-precision hardened guide shaft structure, high parallelism, operating error can be controlled within 0.05mm, is a high-precision flat screen printing machine commonly used in the form of institutions;
  • Widely used in high-precision screen printing tasks such as: circuit boards, dot printing, membrane switch, ink layer thickness requirements of the printing area.


Glass Decorate Printing Machine

Application

  • Widely used in Glass printing field;
  • With UV Curing Machine, Can finish many UV special printing process for UV package industry.
  • Suitable for printing Mobile windows ;
  • Suitable for printing water transfer label and heat transfer label through diffrent process;
  • The machine panel, plastic parts, Paper, furniture industry, glass industry, circuit board industry, film, wooden case, Precision Electron circuit

Technical Parameters

Item PS-100180PVH PS-120240PVH
Printing height(mm)
0-20 0-20
Air(liter/min) 55 60
Worktable dimension(mm) 1400×2300 1600×2600
Max. frame size(mm) 1600×2600 1800×3000
Max. printing area(mm) 1000×1800 1200×2400
Max. printing speed(pcs/h) 400 300
Max Stroke of up-and-down frame(mm)
200 200
Max stroke of Squeegee(mm)
1800 2400
Squeegee motor wattage(w)
500 500
Table Precision(mm)
+-0.13
+-0.13
Package dimension(mm)
2.51×1.26×1.63
3.35×1.96×1.63
G.W.(kg) 541
570
Works supply

380 V-220 V Power supply; 5-7 Bar compress air


Advantage

1) the four-column structure, the platform inside and outside of the platform, the web version vertically up and down, the printing head left and right.
2) the platform, the web version and the printing process adopt the independent drive source, the motion coordination, the speed is stable adjustable.
3) PLC control system and man-machine interface.
4) high strength alloy drawing aluminum printing girder.
5) variable frequency motor drives the printing tool holder, photoelectric eye control stroke, independent adjustment, intelligent quantitative control speed.
6) the printing driven guide adopts the precision orientation of the straight square guide rail.
7) fluctuation motor drive screen and printing girder up and down, smooth movement.
In Taiwan, the line guide rail of silver 50 is synchronized to the same direction.
9) the overall fine grinding stainless steel platform runs in a straight line to the printing position and the upper material.
10) the printing platform is operated by Taiwan intelligent numerical control reduction motor drive, linear square guide rail precision orientation, photoelectric eye precise control positioning.
11) the upper material is on the outer end and runs to the other end for the printed area namely the inner end.
12) the printing platform with fan, can choose long time adsorption and automatic suction mode.
13) printing platform level and vertical direction with precision fine tuning handle, fine tuning precision, color matching for easy edition.
14) the operation interface has a variety of humanized printing modes, automatic printing indirect time digital control (1~9 seconds).
15) the independent design of the head lifting device, scraper/return ink knife, net edition loading and unloading and screen cleaning are convenient.
16) the control device of the right and left net clamping arm is easy to adjust. Pneumatic interlocking fixed screen device.
17) the Angle of the scratch and the return ink can be adjusted, and the pneumatic automatic synchronizing off the net device.
18) printing scraper with anti-drop ink system to ensure more uniform printing color.

Looking for ideal Plain Large Format Screen Printing Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Advestering Plain Screen Printing Machine are quality guaranteed. We are China Origin Factory of Poster Plain Precision Screen Printing Machine. If you have any question, please feel free to contact us.
