hot selling easy operation Tabletop Precision Screen printing machine

Share to:
Unit Price: USD 1750 / Set/Sets
Min.Order Unit Price
1 Set/Sets USD 1750 / Set/Sets
Payment Type: L/C,T/T
Terms of Trade: FOB,CIF
Min. Order: 1
Unit Price: USD
Basic Info
Model No.:ST-3050PV
Type of printing plate: Screen Printer
Applicable industry: Hotels, Machinery Repair Shops, Farms, Home Use, Food Shop, Food &Amp; Beverage Shops
Out-of-warranty service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Where to provide local services (in which countries are there overseas service outlets): Thailand, Australia, Argentina, Uae, Sri Lanka, South Africa
Showroom location (in which countries are there sample rooms overseas): Brazil, Indonesia, Mexico, Thailand, Argentina, Uae, Sri Lanka
status: New
place of origin: China
use: Label Printer, Card Printer, Bill Printer, Cloths Printer
degree of automation: Semi-Automatic
Printing color number and surface number: Single Color
warranty period: 1 Year
Core selling point: Easy To Operate, High-Accuracy, Low Noise Level, High Safety Level
Marketing type: Hot Product 2019, Ordinary Product
Mechanical test report: Provided
Video factory inspection: Provided
Core component warranty period: 1 Year
Core components: Motor, Engine
Table Size: 300*500mm
Additional Info
Packaging: Wooden case
Productivity: 50 sets/month
Brand: KC
Transportation: Ocean
Place of Origin: Dongguan
Supply Ability: 50 sets/month
Certificate: CE Certificate
Port: Shenzhen,Guangzhou,Hongkong
Product Description

Samples

     The reduced version of the desktop flat Screen Printing Machine is designed to meet the needs of users in the field of screen printing processing with small investment in the market. It has all the functions of the flat screen printing machine, but the price is very low, and it can print almost all flat products.
       It has no chassis and can be operated on the table. It uses pneumatic control and requires an additional purchase of an air compressor; it can also be installed with a suction table and a T-slot table. The suction table is used for printing paper and film, T The groove table is suitable for printing three-dimensional injection molding products.
      In terms of precision, its printing area is small, and its precision is completely suitable for most products, and it is also considered to use linear guide rails to control the screen up and down, and it can basically meet the requirements for color registration.

258
Machine description


Tabletop Precision Screen printing machine

Cast aluminum alloy beams, pneumatic lift mode, pneumatic printing control, printing smooth, high precision, more convenient, fast;
Scraper mechanism using high-precision rodless cylinder control, smooth operation, scraping ink back to ink are used brand-name cylinder mechanism, easy to adjust.

Tabletop Precision Screen printing machine//Feature

  • Vacuum table to facilitate the production of Soft and thin , suitable for Printing Paper, film and UV Coating Process;
  • Screen form up and down movement of contact with the table, suitable for hand-placed and remove the product;
  • Distance of the screen and table to the flexibility to adjust for different heights of the product silk screen;
  • Screen form Clamping device free to adjust to fit different sizes of screen;
  • Screen Plate clamping device can be adjusted Front and back, left and right, up and down, the angle of the fine-tuning in order to fine-tune the exact location of the pattern in the product above;
  • Stroke of the scraper can be flexibly adjusted the pattern to suit different size;
  • Squeegee pressure can be individually adjusted to fit any high-precision screen printing;
  • Microcomputer program control operations;
  • Rubber Squeegee and screen frame controller by High precision liner guide rial.
  • 4-Digit auto counter; to facilitate the measurement of production efficiency.

Tabletop Precision Screen printing machine//Parameters

  • Max printing thickness: 150 mm;
  • Air consumption: 60Litre/Min;
  • Dimension of working table: 300×500mm;
  • Max printing areas: 290×490mm;
  • Max printing speed: 1000Pcs/H;
  • Max frame dimension: 500×750mm;
  • Compress air: 5-7 bar;
  • Stroke of cylinder up and down:125mm;
  • Stroke of Squeegee: 500mm;
  • Table Precision: 0.05mm;
  • Rang adjustment of table: 10mm

Tabletop Precision Screen printing machine//Advantage

  • Vacuum table to facilitate the production of Soft and thin , suitable for Printing Paper, film and UV Coating Process;
  • Screen Forme up and down movement of contact with the table, suitable for hand-placed and remove the product;
  • Distance of the screen and table to the flexibility to adjust for different heights of the product silk screen;
  • Screen forme Clamping device free to adjust to fit different sizes of screen;
  • Screen Plate clamping device can be adjusted Front and back, left and right, up and down, the angle of the fine-tuning in order to fine-tune the exact location of the pattern in the product above;
  • Stroke of the scraper can be flexibly adjusted the pattern to suit different size;
  • Squeegee pressure can be individually adjusted to fit any high-precision screen printing;
  • Microcomputer program control operations;
  • 4-Digit auto counter; to facilitate the measurement of production efficiency



Solution
