low cost Tabletop Cylinder screen printing machine

Model No.:ST-60S

Type of printing plate: Screen Printer

Applicable industry: Restaurant, Home Use, Food Shop, Printing Shops, Energy &Amp; Mining, Food &Amp; Beverage Shops, Advertising Company

Out-of-warranty service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Where to provide local services (in which countries are there overseas service outlets): Mexico, Russia, Thailand, Japan, Australia, Morocco, Argentina, South Korea, Uae

Showroom location (in which countries are there sample rooms overseas): Kenya, Argentina, Chile, Uae, Algeria, Sri Lanka, South Africa

status: New

place of origin: China

use: Paper Printer, Label Printer, Card Printer, Bill Printer

degree of automation: Semi-Automatic

Printing color number and surface number: Single Color

warranty period: 1 Year

Core selling point: Easy To Operate, Low Noise Level

Marketing type: Ordinary Product, New Product 2019

Mechanical test report: Provided

Video factory inspection: Provided

Core component warranty period: 1 Year

Core components: Motor, Plc

Packaging: Wooden case

Productivity: 30 Sets/month

Brand: KC

Transportation: Ocean

Place of Origin: Dongguan

Supply Ability: 100 Sets/month

Certificate: CE Certificate

Port: Shenzhen,Guangzhou,Hongkong

Tabletop Cylinder Screen Printing Machine



Samples


Description

    80mm in diameter, suitable for printing less, hollow plastic bottles, hose, there is a slight taper of the hard and soft surface material color screen.

Used in baby bottles, cosmetic bottles, medicine bottles, filters, ignition and other hollow containers monochrome screen printing;

With surface UV Curing Machine M-1030UVS can be UV screen printing of plastic containers;

Solvent ink for screen printing, UV screen printing inks, screen printing ink printing a variety of functions;

Upper and lower part of Screen Plate, take place after the table automatically lifting the work piece;

You can use the foot switch for automatic operation, the safety factor greatly increased;

Multi-type screen printing machine, Both printing round objects and printing taper and flat objects, hardware replacement only way a simple gas conversion, will be able to achieve a multi-functional , and reduce costs.

ST-60S Screen printing Machine //Parameters

• The max printing thickness: 200 MM;
• Air consumption: 75 Lit/Min;
• Outline size: 1080×850×1280MM;
• The max printing area : 200×250MM;
• Dimension of working table: 250mm×300mm;
• Max printing speed: 1300Pc/H;
• Max frame dimension: 410×350mm;
• Stroke of Squeegee: 250mm;
• Stroke of Table cylinder: 60mm;
• Max Diameter of Products: 75mm;
• Max length of Products: 300m

Advantage

• Choose clamp-type Workbench can be inflatable, or may not be blowing, can be placed all types of round, oval-shaped substrates;
• Contact with the substrate , up and down of screen plate, to facilitate the placement of the substrates and removed;
• High Precision axis control. Working table up and down, smooth running, accuracy up to 0.07mm;
• High Precision axis control movement. Screen printing pressure is uniform and reliable, the accuracy up to 0.07mm;
• Self-balance scraper technology and back blade, to ensure uniformity of ink, ink formation;
• Microcomputer control program operations, set up a variety of modes;
• Four counts digital LED count, high degree of automation;
• Printed Stroke mechanical adjustments, adjust the speed of integrated circuit digital.
• Around the screen frame, up and down the emblem of the tune, overlay accuracy, tuning and quick



Catalogue

Structure

Details

Product Categories : Screen Printing Machine > Tabletop Screen Printer
